Kubernetes Cluster on Ubuntu 22.04: A Step-by-Step Guide

Hey everyone! So, you’re looking to set up a Kubernetes cluster on Ubuntu 22.04 , huh? Awesome! You’ve come to the right place, guys. Getting Kubernetes up and running can seem a bit daunting at first, especially if you’re new to the whole container orchestration scene. But don’t sweat it! This guide is designed to break down the process into manageable steps, making it super clear and, dare I say, even fun . We’ll be diving deep into everything you need to know, from prepping your servers to deploying your first application. So, grab your favorite beverage, get comfortable, and let’s get this cluster built!

Why Ubuntu 22.04 for Your Kubernetes Cluster?

First off, why Ubuntu 22.04, also known as ‘Jammy Jellyfish’? Well, this LTS (Long Term Support) release from Canonical is a fantastic choice for running your Kubernetes cluster . It’s got solid stability, a massive community backing, and is generally a breeze to work with. Plus, it supports the latest software versions, which is crucial when you’re dealing with cutting-edge tech like Kubernetes. When you’re building the foundation for your containerized applications, you want a stable, well-supported OS underneath. Ubuntu 22.04 delivers just that. It’s packed with newer kernel versions, enhanced security features, and excellent hardware compatibility, all of which contribute to a robust Kubernetes environment. Think of it as building a skyscraper – you need a really solid foundation, and Jammy Jellyfish is just that. For anyone serious about deploying scalable, reliable applications, choosing the right operating system is paramount, and Ubuntu 22.04 definitely ticks all the boxes. We’re going to assume you have at least two Ubuntu 22.04 machines ready to go – one for the control plane (master node) and at least one for the worker nodes. The more worker nodes you have, the more resilient and scalable your cluster will be, but let’s start simple with one of each. Ensure these machines have static IP addresses; this is super important for reliable cluster communication. You can set these up via your network configuration files or through your router’s DHCP reservation. Don’t forget to update your system packages on all nodes before we start! Run sudo apt update && sudo apt upgrade -y on each machine. This ensures you’re starting with the latest security patches and software versions, which is always a good practice in the sysadmin world.

Prerequisites: What You’ll Need

Before we jump into the nitty-gritty of setting up our Kubernetes cluster on Ubuntu 22.04 , let’s make sure you’ve got all your ducks in a row. Having the right prerequisites will save you a ton of headaches down the line. Seriously, guys, don’t skip this part! We’re talking about having at least two machines (virtual or physical) running Ubuntu 22.04 LTS. One will be your control plane node (the brain of the operation), and the others will be your worker nodes (where your applications actually run). For a serious setup, you’ll want multiple worker nodes, but for learning, one of each is perfect. Make sure each machine has a unique hostname and a static IP address . This is non-negotiable for stable cluster communication. You can set static IPs via your network interface configuration files (e.g., /etc/netplan/ ) or by reserving IPs in your router’s DHCP settings. Trust me, relying on dynamic IPs for cluster nodes is asking for trouble. Also, you’ll need SSH access to all these machines, preferably with passwordless SSH key authentication set up between your master and worker nodes. This makes running commands across your machines way easier. On the software side, you’ll need curl and gnupg installed on all nodes, as we’ll use them to add repositories and download necessary packages. You can install them with sudo apt install -y curl gnupg . Finally, and this is a big one, you need to disable swap on all nodes. Kubernetes doesn’t play nicely with swap enabled. To do this, run sudo swapoff -a and then comment out the swap line in your /etc/fstab file. This ensures swap doesn’t get re-enabled after a reboot. It sounds like a lot, but these steps are crucial for a stable and performant Kubernetes cluster. Get these sorted, and you’re golden!

Step 1: Preparing Your Nodes (Master & Workers)

Alright, folks, let’s get our Ubuntu 22.04 machines ready for the Kubernetes fiesta! This preparation step is super important. Think of it like prepping your kitchen before you start cooking – you want everything clean, organized, and ready to go. We need to make sure all our nodes (master and workers) are speaking the same language and have the necessary tools installed. First things first, let’s update our package lists and upgrade existing packages on all your nodes. Run this command on each machine: sudo apt update && sudo apt upgrade -y . This ensures you’re running the latest software and security patches, which is always a good idea, especially when setting up critical infrastructure like a Kubernetes cluster. Next up, we need to enable some kernel modules and configure sysctl parameters. These settings help optimize network traffic and ensure Kubernetes components can function correctly. On each node, create a new sysctl configuration file: sudo nano /etc/sysctl.d/kubernetes.conf . Inside this file, add the following lines:

net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1

Save the file (Ctrl+X, then Y, then Enter in nano) and apply these settings immediately with: sudo sysctl --system . This command loads the new configuration. Now, let’s disable swap . Kubernetes requires swap to be disabled to function optimally. If swap is enabled, it can lead to performance issues and unexpected behavior. To disable it temporarily, run sudo swapoff -a . To make this change permanent, you need to edit the /etc/fstab file. Open it with sudo nano /etc/fstab and find the line that refers to swap (it usually looks something like /dev/sdaX none swap sw 0 0 ) and add a ‘#’ at the beginning of the line to comment it out. Save the file. Finally, we need to install containerd , the container runtime that Kubernetes will use. It’s a lightweight, powerful option. Run the following commands on each node to install and configure containerd:

sudo apt update
sudo apt install -y containerd

# Create default configuration file if it doesn't exist
if [ ! -f /etc/containerd/config.toml ]; then
  sudo mkdir -p /etc/containerd
  sudo containerd config default | sudo tee /etc/containerd/config.toml
fi

# Enable systemd cgroup driver
sudo sed -i 's/SystemdCgroup = false/SystemdCgroup = true/g' /etc/containerd/config.toml

# Restart containerd to apply changes
sudo systemctl restart containerd
sudo systemctl enable containerd

This installs containerd, generates its default configuration, ensures the SystemdCgroup option is set to true (which is important for compatibility with systemd, the init system used by Ubuntu), and then restarts and enables the service. Phew! That’s a lot, but getting these nodes prepped correctly is the bedrock of a successful Kubernetes setup. You’ve just laid a solid foundation, guys!

Step 2: Installing Kubernetes Components (kubeadm, kubelet, kubectl)

Now that our nodes are prepped and ready to party, it’s time to install the core Kubernetes tools: kubeadm , kubelet , and kubectl . These are the essential pieces of software that will allow us to bootstrap and manage our cluster. We’ll install these on all nodes, including the master and workers, because they all need to understand how to interact with the cluster. Let’s start by adding the official Kubernetes package repository to your system. This ensures you get the latest stable versions. First, you need to download the Google Cloud public signing key and add it to your system’s keyring:

curl -fsSL https://pkgs.k8s.io/core:/stable:/v1.28/deb/Release.key | sudo gpg --dearmor -o /etc/apt/trusted.gpg.d/kubernetes-archive-keyring.gpg

(Note: Replace v1.28 with the Kubernetes version you intend to use if needed. Using the latest stable is generally recommended.)

Next, add the Kubernetes APT repository itself. This tells your system where to find the Kubernetes packages:

echo 'deb [signed-by=/etc/apt/trusted.gpg.d/kubernetes-archive-keyring.gpg] https://pkgs.k8s.io/core:/stable:/v1.28/deb/ /' | sudo tee /etc/apt/sources.list.d/kubernetes.list

(Again, adjust the version in the URL if necessary.)

Now that the repository is added, we need to update your package list again so your system knows about the new packages available:

sudo apt update

Before we install, there’s one crucial step: we need to hold the versions of kubeadm , kubelet , and kubectl . This prevents them from being automatically upgraded by apt upgrade in the future, which could potentially break your cluster if you’re not ready for it. Run this command:

sudo apt-mark hold kubeadm kubelet kubectl

Now, we can finally install the actual packages:

sudo apt install -y kubeadm kubelet kubectl

Once the installation is complete, it’s a good idea to verify that everything is installed correctly. You can check the versions with:

kubeadm version

And confirm that the kubelet service is enabled (it will start automatically once the cluster is initialized):

sudo systemctl status kubelet

You should see that the kubelet service is active and running, or at least enabled. If it’s not running yet, that’s fine because it needs a cluster configuration to actually start up properly. We’ve now installed the brains and the communication tools for our Kubernetes cluster. High five, guys! Next up, we initialize the control plane.

Step 3: Initializing the Control Plane (Master Node)

Alright, team, this is where the magic happens! We’re going to initialize the control plane on our designated master node using kubeadm . This command sets up all the necessary components like the API server, scheduler, and controller manager, turning our Ubuntu 22.04 machine into the heart of our Kubernetes cluster. Make sure you’re logged into your master node for this step. First, we need to configure kubeadm to use the correct network settings. Run the following command. Replace [MASTER_NODE_IP] with the actual IP address of your master node, and [POD_CIDR] with the IP address range you want to use for your pods. A common choice is 10.244.0.0/16 if you plan to use Flannel as your CNI plugin later.

sudo kubeadm init --pod-network-cidr=10.244.0.0/16 --apiserver-advertise-address=[MASTER_NODE_IP]

This command might take a few minutes to complete. kubeadm will pull the necessary container images, set up the control plane components, and generate some important configuration files. Once it’s finished, you’ll see a success message, and critically, you’ll get a kubeadm join command. Copy this command down and save it somewhere safe! It contains a token and a discovery hash needed to join worker nodes to your cluster. It will look something like this:

kubeadm join [MASTER_NODE_IP]:6443 --token [TOKEN]
    --discovery-token-ca-cert-hash sha256:[HASH]

After kubeadm init completes, you need to configure kubectl for your regular user so you can interact with the cluster. Run these commands:

mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

Now you can test if kubectl is working by running:

kubectl get nodes

You should see your master node listed, but it will likely be in a NotReady status. That’s normal for now because we haven’t set up a Container Network Interface (CNI) plugin yet, which is essential for pod networking. Also, the node might be SchedulingDisabled because it doesn’t have a CNI. We’ll fix that in the next steps. You’ve officially bootstrapped your Kubernetes control plane, guys! Give yourselves a pat on the back. The next crucial step is to get your worker nodes connected.

Step 4: Installing a Pod Network (CNI Plugin)

Okay, so we’ve got our control plane up and running, but our nodes are still NotReady . Why? Because Kubernetes needs a way for pods on different nodes to talk to each other – that’s where a Container Network Interface (CNI) plugin comes in. Think of it as setting up the roads and highways for your container traffic. Without it, pods can’t communicate effectively across the cluster. There are several CNI options available, like Calico, Flannel, Weave Net, and Cilium. For this guide, we’ll use Flannel , as it’s simple to set up and works great for most use cases, especially for getting started. We’ll install Flannel using a YAML manifest file. First, make sure you’re still on your master node and that kubectl is configured correctly (you should be able to run kubectl get nodes ). Now, apply the Flannel manifest. You can usually find the latest manifest on the Flannel GitHub repository, but here’s a common one for recent Kubernetes versions (ensure it matches your Kubernetes version if possible):

kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml

This command downloads the YAML definition from the specified URL and applies it to your cluster. kubectl will create the necessary DaemonSet and ConfigMap resources for Flannel. It might take a minute or two for the Flannel pods to start running on all your nodes (including the master). You can monitor their status with:

kubectl get pods -n kube-flannel

Once the Flannel pods are running, your nodes should transition from NotReady to Ready . Let’s verify this. Run the kubectl get nodes command again:

kubectl get nodes

You should now see all your nodes listed with a Ready status! 🎉 This means your cluster’s network is properly configured, and your nodes are ready to accept workloads. If your nodes are still not ready, double-check the sysctl settings ( net.bridge.bridge-nf-call-iptables and net.ipv4.ip_forward ) and ensure containerd is running correctly on all nodes. Sometimes, a reboot of the nodes after applying sysctl settings can also help. With a working CNI, our cluster is much closer to being fully functional. We’ve got networking sorted, so now it’s time to bring our worker nodes into the fold!

Step 5: Joining Worker Nodes to the Cluster

Alright, guys, the moment of truth! We’ve set up the control plane, installed the network, and now it’s time to add our worker nodes to the party. Remember that kubeadm join command we saved earlier from the kubeadm init output on the master node? This is where we use it. If you lost it, don’t panic! You can generate a new join command on the master node with these commands:

On the master node:

# Generate a new token (expires in 24 hours by default)
openssl x509 -in /etc/kubernetes/pki/ca.crt -noout -text | grep 'Subject:'

# Get the CA cert hash
openssl x509 -pubkey -in /etc/kubernetes/ca.pem -noout | openssl sha256

# Get a new token
kubeadm token create --print-join-command

This will output a command similar to the one you got initially. Copy that entire command. Now, SSH into each of your worker nodes one by one. Once you’re logged into a worker node, paste and run the kubeadm join command you copied. It will look something like this (don’t use this exact one, use the one generated for your cluster!):

sudo kubeadm join 192.168.1.100:6443 --token abcdef.1234567890abcdef \
    --discovery-token-ca-cert-hash sha256:1234567890abcdef1234567890abcdef1234567890abcdef1234567890abcdef

Run this command with sudo on each worker node. This command tells the worker node how to find the master node (using its IP address and port 6443) and how to authenticate itself using the token and CA certificate hash. If the command succeeds, you’ll see a message indicating that the node has joined the cluster successfully and is now ready to accept pods.

Now, head back over to your master node . Run the kubectl get nodes command again:

kubectl get nodes -o wide

(The -o wide flag gives you more information, including the internal and external IP addresses of your nodes.)

You should now see your newly added worker node(s) listed, and they should have a Ready status! If a node doesn’t become Ready within a few minutes, check the kubelet service status on that specific worker node ( sudo systemctl status kubelet ) and ensure it can reach the master node’s IP address and port 6443. Also, verify that the CNI pods (Flannel in our case) are running on the worker node ( kubectl get pods -n kube-flannel ). Congratulations, you’ve successfully added worker nodes to your Kubernetes cluster on Ubuntu 22.04 ! You now have a functioning, multi-node Kubernetes environment ready for deployment.

Step 6: Deploying Your First Application

Woohoo! You’ve made it! Your Kubernetes cluster on Ubuntu 22.04 is up, running, and ready to host some applications. It’s time for the fun part: deploying something! Let’s deploy a simple Nginx web server. We’ll create a Kubernetes Deployment to manage the Nginx pods and a Service of type LoadBalancer to expose it to the outside world. You can do this using kubectl commands or by writing a YAML manifest file. Using a YAML file is the recommended approach for managing your applications in Kubernetes, as it provides a declarative way to define your desired state. Let’s create a file named nginx-app.yaml and add the following content:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
  labels:
    app: nginx
spec:
  replicas: 3 # We want 3 instances of our Nginx pod
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:latest # Use the latest Nginx image
        ports:
        - containerPort: 80
--- # Separator for the next resource
apiVersion: v1
kind: Service
metadata:
  name: nginx-service
spec:
  selector:
    app: nginx # Selects pods with the label 'app: nginx'
  ports:
    - protocol: TCP
      port: 80 # The port the service will be available on
      targetPort: 80 # The port on the pods to forward traffic to
  type: LoadBalancer # Exposes the service externally using a cloud provider's load balancer, or MetalLB if configured

Save this file. Now, apply it to your cluster using kubectl :

kubectl apply -f nginx-app.yaml

Kubernetes will now create a Deployment named nginx-deployment with 3 replicas of the Nginx container. It will also create a Service named nginx-service . Since we’ve specified type: LoadBalancer , Kubernetes will try to provision an external load balancer. Important Note: If you’re running this on bare-metal or in a lab environment like this without a cloud provider, the LoadBalancer type won’t automatically work unless you have a load balancing solution like MetalLB configured. For a basic setup, you might initially see the service stuck in a Pending state. If you want to access it immediately without MetalLB, you could change the service type to NodePort and access it via http://<any-node-ip>:<node-port> . To check the status of your deployment and service, run:

kubectl get deployments
kubectl get pods
kubectl get services

You should see your nginx-deployment with 3 available pods, and nginx-service with an assigned IP address (if using MetalLB or a cloud provider) or a NodePort . If you used NodePort , find the assigned NodePort (e.g., 3xxxx) and access Nginx via http://<your-master-node-ip>:<nodeport> or http://<your-worker-node-ip>:<nodeport> . And there you have it! Your first application running on your very own Kubernetes cluster on Ubuntu 22.04 . You’ve come a long way, guys, from setting up nodes to deploying live applications. This is just the beginning of your Kubernetes journey!
